| Length |
400 mm (15.7 in.)
|
| Width |
441 mm (17.4 in.)
|
| Height |
177 mm (7.0 in.)
|
| Weight |
9.5 kg (20.9 lbs.)
|
| Dimming |
0 – 100%, coarse & fine control
|
| Shutter |
Strobe & pulse effects, instant open and blackout
|
| Control systems |
USITT DMX512/1990 with RDM
|
| DMX channels |
1, 4, or 8
|
| RDM compliance |
ANSI/ESTA E.120
|
| Interface |
Control panel with backlit LCD display
|
| Beam angle |
70°
|
| Color |
Black
|
| Housing |
High impact flame retardant thermoplastic and aluminum
|
| Protection rating |
IP20
|
| Mounting points |
Adjustable bracket, surface or truss mount
|
| Location |
Indoor location only
|
| Orientation |
Any
|
| Minimum distance to illuminated surfaces |
0.5 m (20 in.)
|
| Minimum distance to combustible materials |
0.1 m (4 in.)
|
| AC power input/output |
Neutrik PowerCon
|
| DMX and RDM data in/out |
3-pin and 5-pin locking XLR
|
| AC power |
100-240 V nominal, 50/60 Hz
|
| Power supply unit |
Auto-ranging electronic switch mode
|
| Fuse |
T 250 V 6.3 A
|
| Maximum total power consumption |
448 W
|
| Typical half-cycle RMS inrush current |
15.5 A at 240 V, 50 Hz
|
| Recommended Miniature Circuit Breaker when power linking |
Type D*
|
| Electrical notes |
*Per IEC 60898/UL489/CSA C22.2 No. 5
|
| 100 V, 60 Hz |
432 W, 4.3 A, PF 0.998
|
| 120 V, 60 Hz |
428 W, 3.6 A, PF 0.996
|
| 230 V, 50 Hz |
426 W, 1.9 A, PF 0.956
|
| Typical Power and Current notes |
Measurements made at nominal voltage. Figures are typical, not maximum, allow for a deviation of +/- 10%.
|
| Cooling |
Convection
|
| Maximum ambient temperature (Ta max.) |
40° C (104° F)
|
| Minimum ambient temperature (Ta min.) |
0° C (32° F)
|
| EU safety |
EN 60598-2-17 (EN 60598-1), EN 62471, EN 62493
|
| EU EMC |
EN 55015, EN 55032, EN 55103-2, EN 61000-3-2, EN 61000-3-3, EN 61547
|
| US safety |
UL 1573
|
| US EMC |
47 CFR 15 Class A
|
| Canadian safety |
CSA C22.2 No. 166
|
| Canadian EMC |
ICES-003 Class A
|
| Australia/NZ |
RCM
|
| Included Items notes |
Power cable, 1.5 m without mains plug
|
| Installation hardware |
Half-coupler clamp: P/N 91602005
G-clamp (vertical hanging suspension only): P/N 91602003
Quick-trigger clamp (vertical hanging suspension only): P/N 91602007
|
| Power connectors |
Power Connector PowerCON Male: P/N 91611795
Power Connector PowerCON Female : P/N 91611794
|
| Cables, 16 A, for connection to power in chains |
Power relay cable 3 x 2.5 mm2, H07RN-F POWCON-POWCON 1.2 m (3.9 ft.): P/N 91611798
Power relay cable 3 x 14 AWG, SJOOW POWCON-POWCON 1.2m (3.9 ft.): P/N 91610175
Power relay cable 3 x 2.5 mm2, H07RN-F POWCON-POWCON 2.5m (8.2 ft.): P/N 91611799
Power relay cable 3 x 14 AWG,SJOOW POWCON-POWCON 2.5m (8.2 ft.) : P/N 91610176
|
| Cables, 16 A, for power input |
Power input cable 3 x 2.5 mm2, H07RN-F OPEN-POWCON 1.5 m (4.9 ft.): P/N 91611800
Power input cable 3 x 14 AWG, SJOOW OPEN-POWCON 1.5 m (4.9 ft.): P/N 91610177
Power input cable 3 x 2.5 mm2, H07RN-F OPEN-POWCON 5.0 m (16.4 ft.): P/N 91611801
Power input cable 3 x 14 AWG, SJOOW OPEN-POWCON 5.0 m (16.4 ft.): P/N 91610178
(H07RN-F are European approved cables, SJOOW are US approved cables)
|
| RUSH BLINDER 1 WW in cardboard box |
P/N 90480150
|
| Safety Cable, SWL 60 kg, BGV C1 / DGUV 17, black |
P/N 91604006
|
| Safety Cable, SWL 60 kg, BGV C1 / DGUV 17, silver |
P/N 91604007
|
| Martin Companion Cable |
P/N 91616091
|
| Martin Companion Software Suite (including firmware uploader) |
Free download from www.martin.com
|
| Martin™ DMX 5.3 Splitter |
P/N 90758150
|
