Ses Mikserleri ve Preamfiler
Opsiyonel Kartlar

Soundcraft
5046678.V
MADI USB Combo Card
1x MADI RJ45 port (e.g. for Soundcraft stagebox via CAT)
1x USB port (DAW connector for recording)
Standard configuration: MADI 32in / 32out, USB 32in / 32out
Optional settings via DIP switch possible e.g. MADI 64in / 32out or USB 0in / 32out
For PC & MAC (Mac OS X from version 10.7.)

Ses Mikserleri ve Preamfiler
Opsiyonel Kartlar

Soundcraft
CAT 5 MADI CARD

Eight-channel line input card with 24 bit, 48kHz A/D Converter, delta-sigma conversion. Transformer- balanced inputs. 7...26 dBu input sensitivity. “Signal present” LED indicator. Inputs on standard 25-pin D-type connector (female).

Ses Mikserleri ve Preamfiler
Opsiyonel Kartlar

Soundcraft
CAT5 DUAL PORT MADI
By adding option cards to the Si range of digital consoles, you can interface your desk with a multitude of analogue and digital systems, whilst expanding I/O count beyond that of the standard console configuration.

Routing to and from the option cards is achieved via the 'Patching' functionality on the console. Further cards are always in development and will provide various solutions for interfacing onto emerging networks or devices.

The number of option cards that may be fitted varies by product model, as follows:


Soundcraft Si Compact 1 card
Soundcraft Si Expression 1 cards
Soundcraft Si Performer 2 cards
Soundcraft Si1 1 card
Soundcraft Si1+ 4 cards
Soundcraft Si2, Si2+ 4 cards
Soundcraft Si3, Si3+ 4 cards
USB Interface Compatibility:
PC: Supports Windows 7, Windows 8 and Windows 10.
Mac: Supports Mac OS 10.7.x Lion through 10.11.x El Capitan

Ses Mikserleri ve Preamfiler
Stagebox

Soundcraft
COMPACT SB 32/16CAT5
The Compact Stagebox is an extension to the range of Soundcraft digital live sound consoles, and adds a low-cost expansion option to the Soundcraft Vi Series, Soundcraft Si Series, Soundcraft Vi1™ and Soundcraft® SI Compact.

The Soundcraft Compact Stagebox offers a high density of I/O connections in only 4U of rack space. The modular unit is fully configurable but is offered with a standard configuration of 32 mic/line inputs, 8 line outputs, 8 channels of AES/EBU outputs and 2 expansion slots for standard Studer D21m I/O cards. The D21m is the I/O architecture for Studer as well as Soundcraft digital mixing systems and allows connection to most popular digital formats, including CobraNet®, AVIOM A-Net®16, Ethersound, ADAT and RockNet. A MADI recording interface can also be fitted to the expansion slots.

It is possible to equip the Compact Stagebox with an additional 16 mic/line input XLR module instead of the output module, providing 48 inputs. In this case, analogue or AES outputs could sill be obtained on D-Type connectors via D21m cards fitted to the expansion slots.

As well as the flexibility of the D21m option card interface, the Compact Stagebox also uses the same Mic/line I/O modules as found in the Soundcraft Vi1 console, and as a result it is possible to move or share modules between console and stagebox, should a different configuration of I/O be required on either the Vi1 or the Stagebox. For example, the 8 line out/AES output card from the Stagebox could be fitted to the Vi1 console in place of a 16ch line output card. Alternatively, the mic input modules can be replaced with output modules if large numbers of outputs are required. When fitting cards to the expansion slots it should be noted that the maxium input and output capacity of the CSB is limited by the MADI console link to 64 in/64 out.

The Compact Stagebox is connected to the host console using either Cat-5 or Optical-fibre MADI, the same way as the larger 64 Mic/line Vi6 Stagebox is hooked up, and shares the same redundant MADI cable capability. Cat5 Version: E947.350000 Optical version: E947351000

The unit comes complete with twin redundant power supplies, thermostatically-controlled fan cooling and full LED status monitoring. An 8ch GPIO interface is also provided.

The Compact Stagebox is ideal for existing owners of Vi Series consoles as a cost-effective method of expanding the input capability by expanding to up to 96 mic/line analogue inputs from remote stageboxes, or as a partner for the Vi1 and Si range of consoles providing cost-effective remote I/O capability in conjunction with the optional MADI interface cards available for those consoles.

Part Numbers

32 IN, 8 LINE+8 AES OUT, CAT5 VERSION E947.350000
32 IN, 8 LINE+8 AES OUT, OPTICAL VERSION E947.351000
32 IN, 16 LINE OUT, CAT5 VERSION 5031234

OPTIONAL UPPER SECTION MODULES ALSO USED ON Vi1 CONSOLE LOCAL I/O
16 MIC/LINE IN A947.043000SP
16 LINE OUT A947.043500SP
8 LINE OUT+8 AES OUT A947.043700SP
16 AES IN+16 AES OUT 5019847.V
Compatibility
Vi1 Si Impact
Vi2 Si Performer
Vi4 Si Expression
Vi6 Si Compact
Vi2-4-600
Vi1000
Vi2000
Vi3000
Vi5000
Vi7000

Ses Mikserleri ve Preamfiler
Stagebox

Soundcraft
COMPACT SB 32/8+8CAT5
The Compact Stagebox is an extension to the range of Soundcraft digital live sound consoles, and adds a low-cost expansion option to the Soundcraft Vi Series, Soundcraft Si Series, Soundcraft Vi1™ and Soundcraft® SI Compact.

The Soundcraft Compact Stagebox offers a high density of I/O connections in only 4U of rack space. The modular unit is fully configurable but is offered with a standard configuration of 32 mic/line inputs, 8 line outputs, 8 channels of AES/EBU outputs and 2 expansion slots for standard Studer D21m I/O cards. The D21m is the I/O architecture for Studer as well as Soundcraft digital mixing systems and allows connection to most popular digital formats, including CobraNet®, AVIOM A-Net®16, Ethersound, ADAT and RockNet. A MADI recording interface can also be fitted to the expansion slots.

It is possible to equip the Compact Stagebox with an additional 16 mic/line input XLR module instead of the output module, providing 48 inputs. In this case, analogue or AES outputs could sill be obtained on D-Type connectors via D21m cards fitted to the expansion slots.

As well as the flexibility of the D21m option card interface, the Compact Stagebox also uses the same Mic/line I/O modules as found in the Soundcraft Vi1 console, and as a result it is possible to move or share modules between console and stagebox, should a different configuration of I/O be required on either the Vi1 or the Stagebox. For example, the 8 line out/AES output card from the Stagebox could be fitted to the Vi1 console in place of a 16ch line output card. Alternatively, the mic input modules can be replaced with output modules if large numbers of outputs are required. When fitting cards to the expansion slots it should be noted that the maxium input and output capacity of the CSB is limited by the MADI console link to 64 in/64 out.

The Compact Stagebox is connected to the host console using either Cat-5 or Optical-fibre MADI, the same way as the larger 64 Mic/line Vi6 Stagebox is hooked up, and shares the same redundant MADI cable capability. Cat5 Version: E947.350000 Optical version: E947351000

The unit comes complete with twin redundant power supplies, thermostatically-controlled fan cooling and full LED status monitoring. An 8ch GPIO interface is also provided.

The Compact Stagebox is ideal for existing owners of Vi Series consoles as a cost-effective method of expanding the input capability by expanding to up to 96 mic/line analogue inputs from remote stageboxes, or as a partner for the Vi1 and Si range of consoles providing cost-effective remote I/O capability in conjunction with the optional MADI interface cards available for those consoles.

Part Numbers

32 IN, 8 LINE+8 AES OUT, CAT5 VERSION E947.350000
32 IN, 8 LINE+8 AES OUT, OPTICAL VERSION E947.351000
32 IN, 16 LINE OUT, CAT5 VERSION 5031234

OPTIONAL UPPER SECTION MODULES ALSO USED ON Vi1 CONSOLE LOCAL I/O
16 MIC/LINE IN A947.043000SP
16 LINE OUT A947.043500SP
8 LINE OUT+8 AES OUT A947.043700SP
16 AES IN+16 AES OUT 5019847.V
Compatibility
Vi1 Si Impact
Vi2 Si Performer
Vi4 Si Expression
Vi6 Si Compact
Vi2-4-600
Vi1000
Vi2000
Vi3000
Vi5000
Vi7000

Ses Mikserleri ve Preamfiler
Stagebox

Soundcraft
MINI STAGEBOX 16i

Mini Stagebox 16i combine high-quality components with a streamlined design, making it easy to add multiple channels of remote-controlled I/O to your Si-series mixing console. The Studer-designed mic preamps provide exceptional sound quality, while the compact form factor offers easy transport and fast configuration. Ideal for live engineers, houses of worship, bands, club owners and corporate installations, Soundcraft Mini Stageboxes allow you to replace heavy, expensive analog snakes with a single RJ45 Cat5 style Ethernet cable.

HIGH-QUALITY COMPONENTS

Soundcraft Mini Stageboxes offer remarkable value while maintaining the industry-leading performance that Soundcraft live solutions are known for. Renowned Studer-designed mic preamps deliver warm, rich sound for live performances and recording events.

COMPREHENSIVE I/O

Soundcraft Mini Stageboxes provide multi-channel MADI I/O via standard Cat5 cabling, eliminating the need to run expensive and heavy analog snakes from the stage to front-of-house mixing positions. Dedicated XLR mic pre inputs allow 32 or 16 simultaneous channels of external analog input. Mini Stagebox 32i offers twelve analog outputs, while Mini Stagebox 16i offers eight analog outputs for easy connection to house and stage monitors and broadcast or streaming feeds.

STREAMLINED DESIGN

A streamlined design provides essential connections and features, including MADI over RJ45 connectors built right onto the chassis. No local hardware configuration or installing option cards are required—simply plug in, power on, select inputs and control remotely using a Soundcraft Si console.

FULL INTEGRATION WITH Si SERIES MIXERS

Mini Stageboxes pair with Soundcraft Si Series mixers to provide remote controlled expanded I/O and intuitive operation during complex mixing scenarios. Si Impact allows owners to add a stagebox for additional inputs, while simultaneously using the existing console inputs. By adding a second MADI option card to the console, customers can add a second stagebox and select which inputs to assign to the 80 mixing channels.



Ses Mikserleri ve Preamfiler
Stagebox

Soundcraft
MINI STAGEBOX 16R

The Mini Stagebox 16R (2U) model providing 16 analogue inputs and 8 line outputs making a 16 x 8 matrix. They connect to any of the Soundcraft Si Expression, Si Compact, Si Performer, Si Series and Vi Series consoles via a MADI card fitted to the option card slot.

The Mini Stagebox models contain an integral PSU so are completely self-contained and sit comfortably stage-side.

The new units are part of the ViSi Connect range of interface options for all Soundcraft mixing consoles which includes the Compact and Vi Stageboxes and a range of option cards such as MADI, AES, CobraNet and AES.

Both models are supplied with the stagebox card installed, plus the corresponding card for an Si series console (Vi console MADI cards sold separately)

Part Numbers



All Regions

Mini Stagebox 16R Cat5 MADI

5036292



Ses Mikserleri ve Preamfiler
Stagebox

Soundcraft
MINI STAGEBOX 32i

Soundcraft Mini Stagebox 32i combine high-quality components with a streamlined design, making it easy to add multiple channels of remote-controlled I/O to your Si-series mixing console. The Studer-designed mic preamps provide exceptional sound quality, while the compact form factor offers easy transport and fast configuration. Ideal for live engineers, houses of worship, bands, club owners and corporate installations, Soundcraft Mini Stageboxes allow you to replace heavy, expensive analog snakes with a single RJ45 Cat5 style Ethernet cable.

HIGH-QUALITY COMPONENTS

Soundcraft Mini Stageboxes offer remarkable value while maintaining the industry-leading performance that Soundcraft live solutions are known for. Renowned Studer-designed mic preamps deliver warm, rich sound for live performances and recording events.

COMPREHENSIVE I/O

Soundcraft Mini Stageboxes provide multi-channel MADI I/O via standard Cat5 cabling, eliminating the need to run expensive and heavy analog snakes from the stage to front-of-house mixing positions. Dedicated XLR mic pre inputs allow 32 or 16 simultaneous channels of external analog input. Mini Stagebox 32i offers twelve analog outputs, while Mini Stagebox 16i offers eight analog outputs for easy connection to house and stage monitors and broadcast or streaming feeds.

STREAMLINED DESIGN

A streamlined design provides essential connections and features, including MADI over RJ45 connectors built right onto the chassis. No local hardware configuration or installing option cards are required—simply plug in, power on, select inputs and control remotely using a Soundcraft Si console.

FULL INTEGRATION WITH Si SERIES MIXERS

Mini Stageboxes pair with Soundcraft Si Series mixers to provide remote controlled expanded I/O and intuitive operation during complex mixing scenarios. Si Impact allows owners to add a stagebox for additional inputs, while simultaneously using the existing console inputs. By adding a second MADI option card to the console, customers can add a second stagebox and select which inputs to assign to the 80 mixing channels.

Mini Stagebox 32i:

  • RJ45/Cat5 connectivity, for 100M runs between stage and mixing console (328 feet)
  • 32 remote controlled mic preamps and AD converters
  • 12 XLR analog line level outputs
  • 3U Rack mount design



Ses Mikserleri ve Preamfiler
Stagebox

Soundcraft
MINI STAGEBOX 32R

The new Mini Stagebox range from Harman's Soundcraft provides a simple solution to stage connectivity offering a lower-cost option for many systems where the modularity and configurability of the larger systems are not required.

The Mini Stagebox 32R (3U) provides 32 analogue inputs and 8 analogue line outputs, with 4 pairs of AES outputs, providing a total I/O capacity of 32 inputs and 16 outputs, with the Mini Stagebox 16R (2U) model providing 16 analogue inputs and 8 line outputs making a 16 x 8 matrix. They connect to any of the Soundcraft Si Expression, Si Compact, Si Performer, Si Series and Vi Series consoles via a MADI card fitted to the option card slot.

The Mini Stagebox models contain an integral PSU so are completely self-contained and sit comfortably stage-side.

The new units are part of the ViSi Connect range of interface options for all Soundcraft mixing consoles which includes the Compact and Vi Stageboxes and a range of option cards such as MADI, AES, CobraNet and AES.

Both models are supplied with the stagebox card installed, plus the corresponding card for an Si series console (Vi console MADI cards sold separately)

Sinyal İşlemciler
Efekt Prosesör

Soundcraft
REALTIME RACK
The result of a unique collaboration between live sound mixing experts Soundcraft and renowned plug-in manufacturer, Universal Audio, the Soundcraft Realtime Rack brings industry-standard UAD studio plug-ins to the Soundcraft platform. The Realtime Rack hardware and software delivers tight integration of Soundcraft Vi consoles and UAD Powered Plug-Ins, with (48 kHz) sub-2 millisecond latency and full snapshot store and recall with Soundcraft’s CUE/Snapshot system. Realtime Rack’s robust SHARC-based processors run audio over standard Optical MADI connections and dual-redundant internal power supplies ensure that audio signals keep running, even in the event of a power supply failure. Soundcraft Realtime Rack brings the stability of DSP and the sound quality that Soundcraft and Universal Audio are known for in a scalable, low-latency processing environment.



UAD Powered Plug-Ins. What Live Sound has been waiting for

Combining the intuitive Vistonics operator interface with pristine sound quality and powerful mixing features, the Soundcraft Vi Series is already established as the first-choice live sound mixing console for touring and installed applications worldwide.

Now the new Soundcraft Realtime Rack provides access to Universal Audio's acclaimed analogue audio processing emulations and award-winning UAD plug-ins. Realtime Rack software gives Vi console operators all the control they need to insert UAD plug-ins on individual channels, auxiliary channels, and master busses - just as easily as real hardware. A comprehensive snapshot system allows total recall of all plug-ins and their settings, while tight network integration with the Vi Series ensures that all settings of the application are stored inside the console.

Two versions are available: The Realtime Rack Ultimate Live with 74 plug-ins available, and the Realtime Rack Core Live with 14 plug-ins. Additional UAD plug-ins can be purchased any time from UA's Online store. The 8.6.3 software update for Realtime Rack makes available a further 46 plug-ins which can be added to either the Ultimate or Core Live units.

The UAD Powered Plug-Ins platform offers the world's most authentic analogue hardware emulations and award-winning audio plug-ins. Powered by Universal Audio's DSP Accelerator hardware, UAD Powered Plug-Ins deliver rich, analogue sound quality that would be difficult or impossible to achieve with native recording systems.

From rare compressors and equalizers, to vintage reverb processors and tape machines, UAD Powered Plug-Ins inject three-dimensional 'out-of-the-box' analogue sound to your mixes.

The Realtime Rack Ultimate Live (74 plug-ins available):
including -
• 1176 Classic Limiter Collection
• 1176LN Legacy Limiter
• 1176SE Legacy Limiter
• API 500 Series EQ Collection
• API Vision Channel Strip
• dbx 160 Compressor
• CS-1 Channel Strip
• Cambridge Equalizer
• Cooper Time Cube Delay/Modulation
• DreamVerb Reverb
• Empirical Labs Fatso JR/SR
• EMT 140 Plate Reverb
• EMT 250 Digital Reverb
• EP-34 Tape Echo
• Fairchild Tube Limiter Collection
• Harrison 32C Equalizer
• Helios 69 Equalizer
• Lexicon 224 Reverb
• Little Labs IBP
• Little Labs VOG
• Manley Massive Passive
• Moog Filter
• MXR Flanger Doubler
• Neve 1073
• Neve 1081
• Neve 31102
• Neve 33609
• Neve 88RS
• Oceanway Studios
• Precision Buss Compressor
• Precision De-Esser
• Precision Enhancer Hz
• Precision Enhancer kHz
• Precision Equalizer
• Precision K-Stereo
• Precision Limiter
• Precision Maximizer
• Pultec Passive EQ Collection
• Pultec EQP-1A Legacy Equalizer
• Pultec Pro Legacy Equalizer
• RealVerb Pro Reverb
• Roland CE-1
• Roland Dimension D
• Roland RE-201
• SPL Transient Designer
• SSL E Channel Strip
• SSL G Bus Compressor
• Studer A800 Tape Machine
• Teletronix LA-2A Limiter Collection
• Teletronix LA-2A Legacy Limiter
• Teletronix LA-3A Limiter
• Trident A-Range

Realtime Rack Core Live (14 plug-ins included):
including -
• 1176LN Legacy Limiter
• 1176SE Legacy Limiter
• dbx 160 Compressor
• CS-1 Channel Strip
• Lexicon 224 Reverb
• Pultec EQP-1A Legacy Equalizer
• Pultec Pro Legacy Equalizer
• RealVerb Pro Reverb
• Studer A800 Tape Machine
• Teletronix LA-2A Legacy Limiter

Any plug-ins from the Ultimate Live and Optional list can be added to the Core unit by purchasing from the Universal Audio website.

Realtime Rack Optional Plug-ins for Ultimate Live and Core Live (46 plug-ins available)
(Available with RTR software version 8.6.3 only)
• UA 610-A Tube Preamp & EQ
• UA 610-B Tube Preamp & EQ
• Neve 1073 Preamp & EQ
• Thermionic Culture Vulture
• Manley Stereo Variable Mu Limiter Compressor
• Ibanez Tube Screamer TS808
• Bermuda Triangle
• Raw Distortion
• Neve 88RS Channel Strip Collection
• Precision Channel Strip (EX-1)
• Precision Delay Modulation (DM-1)
• Precision Delay Modulation Long (DM-1L)
• Precision Reflection Engine (RS-1)
• AKG BX 20 Spring Reverb
• Oxide Tape Recorder
• Fender® '55 Tweed Deluxe
• Dangerous BAX EQ Mix (Brainworx)
• Dangerous BAX EQ Master (Brainworx)
• Brainworx bx_refinement
• Brainworx bx_saturator
• Chandler Limited GAV19T Amplifier (Brainworx)
• Valley People Dyna-mite (Softube)
• Tonelux Tilt (Brainworx)
• Tonelux Tilt Live (Brainworx)
• elysia• mpressor (Brainworx)
• elysia• alpha compressor (Brainworx)
• AMS RMX16 Digital Reverb (AMS-Neve)
• Summit Audio TLA-100A Compressor (Softube)
• Vertigo Sound VSC-2 Compressor (Brainworx)
• Vertigo Sound VSM-3 Mix Satellite (Brainworx)
• MDWEQ5 Parametric Equalizer (MDW)
• Friedman BE-100
• Friedman DS-40
• Sound Machine Wood Works
• Marshall Plexi Super Lead 1959 (Softube)
• Tube-Tech CL 1B Compressor (Softube)
• Ampeg SVT-VR Bass Amplifier (Brainworx)
• Ampeg SVT-3 PRO Bass Amplifier (Brainworx)
• Tube-Tech EQ Collection (Softube)
• Eventide H910 Harmonizer
• Marshall Silver Jubilee 2555 (Softube)
• Marshall Bluesbreaker 1962 (Softube)
• Marshall JMP 2203 (Softube)
• Brainworx bx_digital V3
• Brainworx bx_digital V3 Mix
• Chandler Limited® Curve Bender Mastering EQ (Softube)

Plug-ins from this list can be added to both the Ultimate Live and Core Live units by purchasing from the Universal Audio website. A 14-day demo/evaluation mode is available for all of the above.


Ses Mikserleri ve Preamfiler
Stagebox

Soundcraft
Vi SB 48/32 CAT5
The 9U Vi Stagebox houses 48 mic/line inputs and 24 analogue line outputs. Mic/line amp gain, 48 V phantom power and 100 Hz lo-cut filter before the A-D converters can all be controlled remotely from the desk.

The Stagebox is available in Standard 48/24 configuration, or can be reconfigured as part-fitted or with alternative cards as required.

Optional AES/EBU, CobraNet®, Ethersound®, Aviom A-Net® 16, Blu Link or Dante cards are available, as well as transformer balanced options for the mic input cards.


Part Numbers
CAT5 VERSION RW5786C

Compatibility
Vi1 Si Impact
Vi2 Si Performer
Vi4 Si Expression
Vi6 Si Compact
Vi2-4-600
Vi1000
Vi2000
Vi3000
Vi5000
Vi7000

Ses Mikserleri ve Preamfiler
Stagebox

Soundcraft
Vi SB 64/32 CAT5
The 9U Vi Stagebox houses 64 mic/line inputs and 32 analogue line outputs. Mic/line amp gain, 48 V phantom power and 100 Hz lo-cut filter before the A-D converters can all be controlled remotely from the desk.

The Stagebox is available in Standard 64/32 configuration, or can be reconfigured as part-fitted or with alternative cards as required.

Optional AES/EBU, CobraNet®, Ethersound®, Aviom A-Net® 16, Blu Link or Dante cards are available, as well as transformer balanced options for the mic input cards.


Part Numbers
CAT5 VERSION RW5786C
OPTICAL VERSION RW5786CO
Compatibility
Vi1 Si Impact
Vi2 Si Performer
Vi4 Si Expression
Vi6 Si Compact
Vi2-4-600
Vi1000
Vi2000
Vi3000
Vi5000
Vi7000

Ses Mikserleri ve Preamfiler
Stagebox

Soundcraft
Vi SB 64/32 OPT
The 9U Vi Stagebox houses 64 mic/line inputs and 32 analogue line outputs. Mic/line amp gain, 48 V phantom power and 100 Hz lo-cut filter before the A-D converters can all be controlled remotely from the desk.

The Stagebox is available in Standard 64/32 configuration, or can be reconfigured as part-fitted or with alternative cards as required.

Optional AES/EBU, CobraNet®, Ethersound®, Aviom A-Net® 16, Blu Link or Dante cards are available, as well as transformer balanced options for the mic input cards.


Part Numbers
OPTICAL VERSION RW5786CO

Compatibility
Vi1 Si Impact
Vi2 Si Performer
Vi4 Si Expression
Vi6 Si Compact
Vi2-4-600
Vi1000
Vi2000
Vi3000
Vi5000
Vi7000

Ses Mikserleri ve Preamfiler
Stagebox

Soundcraft
COMPACT-STAGEBOX

The Compact Stagebox is an extension to the range of Soundcraft digital live sound consoles, and adds a low-cost expansion option to the Soundcraft Vi Series, Soundcraft Si Series, Soundcraft Vi1™ and Soundcraft® SI Compact.

The Soundcraft Compact Stagebox offers a high density of I/O connections in only 4U of rack space. The modular unit is fully configurable but is offered with a standard configuration of 32 mic/line inputs, 8 line outputs, 8 channels of AES/EBU outputs and 2 expansion slots for standard Studer D21m I/O cards. The D21m is the I/O architecture for Studer as well as Soundcraft digital mixing systems and allows connection to most popular digital formats, including CobraNet®, AVIOM A-Net®16, Ethersound, ADAT and RockNet. A MADI recording interface can also be fitted to the expansion slots.

It is possible to equip the Compact Stagebox with an additional 16 mic/line input XLR module instead of the output module, providing 48 inputs. In this case, analogue or AES outputs could sill be obtained on D-Type connectors via D21m cards fitted to the expansion slots.

As well as the flexibility of the D21m option card interface, the Compact Stagebox also uses the same Mic/line I/O modules as found in the Soundcraft Vi1 console, and as a result it is possible to move or share modules between console and stagebox, should a different configuration of I/O be required on either the Vi1 or the Stagebox. For example, the 8 line out/AES output card from the Stagebox could be fitted to the Vi1 console in place of a 16ch line output card. Alternatively, the mic input modules can be replaced with output modules if large numbers of outputs are required. When fitting cards to the expansion slots it should be noted that the maxium input and output capacity of the CSB is limited by the MADI console link to 64 in/64 out.

The Compact Stagebox is connected to the host console using either Cat-5 or Optical-fibre MADI, the same way as the larger 64 Mic/line Vi6 Stagebox is hooked up, and shares the same redundant MADI cable capability. Cat5 Version: E947.350000 Optical version: E947351000

The unit comes complete with twin redundant power supplies, thermostatically-controlled fan cooling and full LED status monitoring. An 8ch GPIO interface is also provided.

The Compact Stagebox is ideal for existing owners of Vi Series consoles as a cost-effective method of expanding the input capability by expanding to up to 96 mic/line analogue inputs from remote stageboxes, or as a partner for the Vi1 and Si range of consoles providing cost-effective remote I/O capability in conjunction with the optional MADI interface cards available for those consoles.



32 IN, 8 LINE+8 AES OUT, CAT5 VERSION E947.350000
32 IN, 8 LINE+8 AES OUT, OPTICAL VERSION E947.351000
32 IN, 16 LINE OUT, CAT5 VERSION 5031234

OPTIONAL UPPER SECTION MODULES ALSO USED ON Vi1 CONSOLE LOCAL I/O
16 MIC/LINE IN A947.043000SP
16 LINE OUT A947.043500SP
8 LINE OUT+8 AES OUT A947.043700SP
16 AES IN+16 AES OUT 5019847.V

Ses Mikserleri ve Preamfiler
Analog Mikserler

Soundcraft
EFX12
The Soundcraft EFX™ Series combines all the features of the popular Soundcraft EPM™ mixer with a built-in 24-bit, digital Lexicon® effects processor, expanding the Soundcraft low-cost, multipurpose compact range.

Recommmended for: Sc checkHouses of WorshipSc checkMusic VenuesSc checkMusicians & BandsSc checkTheatres

The Soundcraft EFX™ Series combines all the features of the popular Soundcraft EPM™ mixer with a built-in 24-bit, digital Lexicon® effects processor, expanding the Soundcraft low-cost, multipurpose compact range.

The Soundcraft EFX mixer uses the same AudioDNA® processor featured in many of the Digitech® and Lexicon outboard equipment including the highly respected Lexicon MX400 processor. With over 35 years experience, the Lexicon name is synonymous with the best reverb and processing in the business, ensuring the finest quality effects not usually found in a console at this price level.

The Effects section fits neatly into the mixers compact framework which is available in 8 or 12 mono input variants, both with 2 stereo channels and an effects send on each channel. There are 32 effects to choose from with a tap tempo function, 3 effects parameter controls and a user effects setting store facility. An effects channel level clip LED and Mute function gives the user even more flexibility.

The emphasis with the Soundcraft EFX is very firmly on quality build and audio performance, with an easy to understand control surface in line with the Soundcraft professional range. The Soundcraft EFX uses the highly-transparent GB30 Mic amp (designed by Graham Blyth for the company’s 30th anniversary, and also used on the larger LX7ii and GB Series professional consoles).The Soundcraft EFX also offers all the features of the Soundcraft EPM most notably a configurable aux send, XLR and ¼" metal jack connector sockets, RCA phono stereo playback inputs and record outputs, 3-band EQ with a swept mid on the mono inputs, 3-band EQ on the 2 stereo inputs, TRS insert sockets, inserts on all mono inputs, ten-segment LED output metering and a headphone output.



1
