| Power Rating |
800 W / 1600 W / 3200W
|
| Frequency Range |
60 Hz - 20 kHz
|
| Dimensions (H x W x D) |
629 mm x 432 mm x 324 mm (375 mm stage height) 24.75 in x 17 in x 12.75 in (14.75" stage height)
|
| Frequency Response |
70 Hz - 20 kHz
|
| Coverage Pattern |
50° x 90° nominal
|
| Crossover Modes |
Passive / Bi-amp
|
| Crossover Frequency |
1.1 kHz
|
| System Maximum SPL |
127 dB SPL continuous (133 dB SPL peak)
|
| System Sensitivity (1w @ 1m) |
98 dB SPL
|
| LF Driver |
1 x JBL 2265H 380 mm (15 in) Differential Drive® woofer 8 Ohms
|
| HF Driver |
1 x JBL 2453H-SL, 38 mm (1.5 in) exit compression driver, 100 mm (4 in) voice coil and neodymium magnet
|
| Nominal Impedance |
8 ohms
|
| Active Tunings |
Tunings available at www.jblpro.com
|
| Enclosure |
Symmetrical stage monitor, 15/18 mm, plywood
|
| Finish |
Black DuraFlex™ finish
|
| Grille |
Powder coated, black, 16 gauge perforated steel with acoustically transparent black screen backing
|
| Input Connectors |
Neutrik® Speakon® NL-4 (x2), one on each end
|
| Net Weight |
21 kg (46.0 lb)
|
